Spherical roller thrust bearings

RKB spherical roller thrust bearings can take over heavy axial loads in one direction and simultaneously radial loads. Due to design of their raceways, they are self-aligning, which makes them insensitive to the shaft deflection or misalignment between shaft and housing. They are mainly manufactured in three configurations, depending on bearing size: EM type, with one-piece machined brass cage guided on the shaft washer; EMEVO type, with one-piece EVO machined brass cage guided on the shaft, where the axial forces are transmitted via the cage-guiding sleeve; and EJ type, with a high-strength pressed steel cage guided on the shaft washer.

Main types

  • Type EM

    • Asymmetrical roller profile
    • One-piece machined brass cage guided on rollers (M)
    • Reinforced and optimized execution (E)
    • Supports unidirectional axial loads and angular misalignment
  • Type EMEVO

    • Asymmetrical roller profile
    • One-piece EVO type machined brass cage guided by a retaining sleeve held in the shaft washer bore
    • Reinforced and optimized execution (E)
    • Supports unidirectional axial loads and angular misalignment
  • Type EMB

    • Asymmetrical roller profile
    • One-piece machined brass cage guided on rollers and featuring a retaining sleeve held in the shaft washer bore (MB)
    • Reinforced and optimized execution (E)
    • Supports unidirectional axial loads and angular misalignment
  • Type EJ

    • Asymmetrical roller profile
    • High strength pressed steel cage (J) guided on shaft washer
    • Reinforced and optimized execution (E)
    • Supports unidirectional axial loads and angular misalignment
